LDR-7015F Soft UHF Washable Tag
LDR-7015F Soft UHF Washable Tag
Pedaran pondok:
Item No.:LDR-7015F
Advantages:
1. Achieve and exceed the industrial washing life of more than 200 times;
2. 100% memory write test;
3. The material and design have passed the reliability test;
4. The product has passed the 100% RF consistency test of Tagformace equipment in Finland and Europe;
Main features:
1. The soft washing label can be customized according to the requirements of customers;
2. The soft washing label can be customized to meet the requirements of MRI test;
3. Soft, no damage to textiles, good handle;
4. The size of chip module is one of the smallest in the international market;
5. It can withstand 60bars pressure;
6. It is one of the few pre drying processes in the global market that can withstand 180 degrees, 30 minutes and 200 times;
Product application:
1. Industrial washing management;
2. Grass leasing management;
3. Standard clothing management and washing management;
4. Work clothes leasing and washing management;
5. Hospital linen and washing management;
6. Military clothing and bedding management;
7. Railway linen management and washing management;
8. Police clothing management;
9. Management personnel;
10. Access control management;
LDR-7015F Soft UHF Washable Tag
| Parameter RFID | |
| Modél No. | LDR-7015F |
| Tipe | Passive UHF RFID Washable Label |
| Protokol | ISO/IEC 18000-6C, EPC Kelas 1 Gen2 |
| Frékuénsi | Di sakuliah dunya 840-960Mhz, AS 902-928mhz, EU 865-868Mhz |
| Chip | NXP Ucode 7（Customized） |
| Mémori | EPC 96 bit, TID 48bits, 32bits |
| Maca&Tulis | Dirojong |
| Baca Range | Fixed: 5.5 m Handheld: 2m |
| ingetan data | 10taun |
| Siklus Programming | 100,000 siklus |
| Parameter fisik | |
| Ukuran | 70X15mm |
| Bahan | Textitles |
| Washing cycles | 200 siklus |
| Heat resistance | -40~ 85℃ (-40~185℉) |
| Pamasangan | Sewing or insert, Direct thermal glue |
| Working temperature | – 25 ℃ ~ + 110 ℃ |
| Storage temperature | – 40 ℃ ~ + 85 ℃ |
| Washing | 100℃ , 60mins, 120 bars |
| Pre-drying in tumbler | 180℃ , 30mins, 200times |
| Tunnel ironing | 180℃ , 30mins, 200times |
| Sterilization process | 134℃ , 20mins, RH 85% |
| Water extractor process | 60 bars |
| Chemical resistance | Endure all chemicals common to the washing endurance |
| Certificate | RoHS |
| Beurat | 0.7g/pc |
Sumuhun, ukuranana bisa ngaropéa nurutkeun sarat customer urang, sarta acuh panjang sarta rubak.
Sumuhun, kami jadi bungah pikeun ngirim anjeun sababaraha sampel ayeuna keur rujukan anjeun. Sampelna gratis, Anjeun ngan perlu nanganan ongkos pangiriman.
Sumuhun, Anjeun tiasa milih bahan jeung chip naon rék.
Pesenan minimum kami nyaéta 500 ~ 1000pcs.
Sumuhun, punten kirimkeun file dina format "AI." atanapi "CDR" kalayan "garisan hébat" ka kami ku email.
Kanyataanna nyaéta warna anu dipidangkeun dina monitor anu urang tingali sareng warna anu dicitak dina produk anu saleresna gaduh bédana. Pikeun pangaruh kualitas pangalusna, Anjeun tiasa masihan kami conto pertandingan atanapi warna Pantone anu tangtu. Urang cocog warna leuwih 90% nu leuwih luhur rata industri tina 80%
Éta gumantung kana metode pengiriman anu dipilih, tag bodas, Biasana, tag bakal dikirim kaluar dina 7 ~ 15 poé sanggeus mayar geus réngsé.
Urutan jaminan dagang disarankeun. Platform Alibaba bakal ngajagi pesenan anjeun tina pamayaran dugi ka pangiriman, atanapi ku T / T, Paypal jeung saterusna.
Sumuhun, kami nyadiakeun jaminan kualitas pikeun 1 taun, iwal karuksakan fisik.
