LDR-G02 UHF RFID Gate Device
LDR-G02 UHF RFID Gate Device
Short Description:
Item No.:LDR-G02
Quick Details
LDR-G02 UHF Gate is a high performance EPC C1G2(18000-6C) protocol UHF tag gate device. Designed upon fully self-intellectual property, it supports fast tag anti-collision operation with high identification rate. It can be directly connected to host, controller and other relative equipment. It can be widely applied in many RFID application systems such as logistics, open conference attendance system, open access control and industrial production process control.
It support RS232, RS485. It can also be customized with Wifi and 4G communication.
Gross Weight:41kg including Wooden packing box Box
LDR-G02 UHF RFID Gate Device
Model:LDR-G02
Dimention:1590*400*50mm(1 panel)、Base Box 203mm
Weight:24KG(1 panel)
Frequency:FCC: 902MHz~928MHz;ETSI:865MHz~868MHz (Optional)
Support Protocal:ISO18000-6C/EPC C1G2、ISO18000-6B (Optional)
Operating Temp.:-20℃~50℃
Storage Temp.:-30℃~70℃
Humidity:5%~95%RH
Power Supply:AC 220V±10%
Power Dissipation:<30W
RF Output Power:0-30dBm(Adjustable)
Effective Reading Distance:0-400cm(Adjustable)
Communication Interface:RJ45/RS232 (WiFi/4G Optional)
Mounting Distance between Cascaded Panel:0.8~1.5m(Maxium 2.2m)
Housing:Acrylic & Metallic Material
Colour:Light Grey, white
Alam:Light & Buzzer
Features
Self-intellectual property
Advanced UHF module, high identification rate
Support RS232 and TCPIP interface
Support buzzer and alarm
Support motion direction detection with embedded infrared sensor
Components
Master Panel*1 Slave Panel*1
10dBi antennas *4 pcs Feeder Line*4pcs
Controller Board & Adaptor* 1pcs(Optional)
RFID Reader module* 1pcs(Optional)
Alarm Unit*1pcs(Device)
Infrared Receiver Units* 2Groups(Optional)
Infrared Connecting Cable * 2Groups
LED Light(Red & Green)*2
Yes, the size can be customized according to customer’s requirement, and indifferent length and width.
Yes, we are so glad to send you some current samples for your reference. The samples are free, you just need to handle the delivery cost.
Yes, you can choose the material and chip what you want.
Our minimum order is 500~1000pcs.
Yes, please send the files in “AI.”or “CDR” format with “greate outlines” to us by email.
The fact is that the colors shown on the monitor we saw and the color printed in actual products have differences. For the best quality effect, you may provide us a match sample or the specify Pantone colors. We match the colour over 90% which is much more above the industry average of 80%
It depends on the shipping method chose, the white tag, Normally, the tags will be sent out within 7~15 days after payment is completed.
The trade assurance order is recommended. Alibaba platform will protect your orders from payment to delivery, or by T/T, Paypal and so on.
Yes, we provide quality assurance for 1 years, except the physical damage.
