LDF-D20L NFC Paper Sticker
LDF-D20L NFC Paper Sticker
Short Description:
Item No.:LDF-D20L
Quick Details
LDF-D20L RFID NFC Sticker comes with size of diameter 20mm, compatible Mifare® Classic Chip and coated paper material. It uses the standards-based, proximity contactless connectivity technology that enables simple and safe two-way interactions between electronic devices, allowing consumers to perform contactless transactions which is specially designed for mobile payment.
Applications
1. NFC posters,NFC device data connection and data transmission
2. Mobile payment, Mobile wallet
3. Product identification, personnel identification management
4. Vending machines etc.
NFC Paper Sticker
| RFID Parameter | |
| Model No. | LDF-D20L |
| Type | HF NFC Sticker |
| Protocol | ISO / IEC 14443 A & 18000-3 |
| Frequency | Worldwide HF 13.56Mhz |
| Chip | Compatible MIFARE Classic® 1K（customizable） |
| Memory | UID 4/7Byte 、User 1K Byte |
| Read&Write | Supported |
| Read Range | 0.1-10cm |
| Data retention | 10years |
| Programming Cycles | 100,000 cycles |
| Physical Parameter | |
| Size | Diameter 20mm （customizable） |
| Substrate Material | Transparent Release Film |
| Antenna Material | Aluminum Etching |
| Surface Material | Coated Paper（customizable） |
| Encode | Supported |
| Installation | Self adhesive |
| Operating temperature | -10℃ ~ 50℃ |
| Operating humidity | 20% ~ 90%RH |
| Package | 3000pcs/roll （customizable） |
| Customized Service | Optional Chips: MIFARE® Series, NTAG® Series Optional Materials: Coated Paper; PVC Paper; Synthetic PP Paper; PET Paper; Optional Glues: Standard Glues; 3M Glues; Strong Glues; Optional Printing: Offset Printing; Barcode Printing; UID Number Printing; UV Printing Optional Crafts: UID encoding; Optional Sizes: Smaller or Bigger |
Yes, the size can be customized according to customer’s requirement, and indifferent length and width.
Yes, we are so glad to send you some current samples for your reference. The samples are free, you just need to handle the delivery cost.
Yes, you can choose the material and chip what you want.
Our minimum order is 500~1000pcs.
Yes, please send the files in “AI.”or “CDR” format with “greate outlines” to us by email.
The fact is that the colors shown on the monitor we saw and the color printed in actual products have differences. For the best quality effect, you may provide us a match sample or the specify Pantone colors. We match the colour over 90% which is much more above the industry average of 80%
It depends on the shipping method chose, the white tag, Normally, the tags will be sent out within 7~15 days after payment is completed.
The trade assurance order is recommended. Alibaba platform will protect your orders from payment to delivery, or by T/T, Paypal and so on.
Yes, we provide quality assurance for 1 years, except the physical damage.
